Product Overview
The Wide-Tire Off-Road Electric Scooter is engineered for heavy-duty utility, last-mile rugged deployment, and recreational multi-terrain leasing operations. Constructed with an extruded 6061-T6 aviation-grade aluminum alloy frame and assembled using robotic MIG welding joints, the chassis is designed to withstand continuous high-torque mechanical loads. The platform features 11-inch pneumatic tubeless off-road tires with puncture-resistant self-sealing liners, paired with dual hydraulic shock absorbers to manage impact forces across gravel, dirt, and uneven surfaces. A brushless DC hub motor integrated directly into the cast aluminum wheel assembly delivers immediate low-end torque for gradient climbing.
Key Features
Structural Material: Main deck and steering stem fabricated from 6061-T6 aluminum alloy, finished with a 25-micron corrosion-resistant matte anodized coating.
Tire Geometry: 11-inch by 4.0-inch pneumatic wide tires featuring deep tread blocks designed to maximize contact patch area on loose terrain, mud, and wet tarmac.
Braking Mechanism: Front and rear 140mm ventilated mechanical disc brakes paired with electronic regenerative braking (EABS) to assist with deceleration and energy recovery.
Power Architecture: Removable lithium-ion battery pack utilizing high-discharge 21700 cylindrical cells, enclosed in an IPX5-rated waterproof compartment with an integrated smart Battery Management System (BMS).
Control & Display: IP65-rated thumb throttle and centralized LCD screen displaying real-time speed, accumulated mileage, selected gear mode, and battery voltage.
Technical Specifications
|
Specification Parameter |
Engineering Metric |
|
Motor Type |
Dual or Single Brushless DC Rear Hub Motor |
|
Rated Motor Power |
1000W (Peak Output: 2000W) |
|
Battery Capacity |
48V / 52V / 60V, 18.2Ah to 23.4Ah Lithium-Ion |
|
Maximum Load Capacity |
150 kg (330 lbs) |
|
Top Speed |
45 km/h to 55 km/h (Configurable per regional regulatory limits) |
|
Maximum Range |
50 km to 70 km per charge (Evaluated under a 75 kg load on flat test tracks) |
|
Incline Capability |
25-degree gradient climb |
|
Charging Duration |
6 to 8 hours using standard 2A/3A smart chargers |
|
Tire Dimensions |
11 x 4.0 inch tubeless pneumatic off-road |
|
Braking System |
Dual Mechanical Discs (Front/Rear) + Regenerative EABS |
|
Chassis Material |
6061-T6 Aluminum Alloy |
|
Net Weight |
32 kg (70.5 lbs) |
Applications
Resort & Campus Fleet Operations: Utilized within large hospitality resorts, university campuses, and industrial sites for personnel transit and security patrols.
Commercial Rental Fleets: Deployed by outdoor recreation and eco-tourism rental agencies operating in beachside or off-road environments.
Industrial Last-Mile Logistics: Applied inside large-scale warehousing facilities and manufacturing plants to expedite internal technician movement across expansive operational floors.
Available Configurations
Motor Drive Variants:
Single-motor rear-wheel drive layout (configured for standard range efficiency) or dual-motor all-wheel drive layout (configured for high-torque off-road acceleration).
Battery Cell Tiering:
Options for standard lithium cells or high-density cells to align with target retail price points or specific range requirements. stop solutions for automated testing,sorting,and precision test fixtures in conjunction with package-level system products.
OEM/ODM Customization:
Laser-etched deck logos, customized handlebar grip materials, firmware speed-cap profiles, and region-specific charging plug standards (EU, US, UK, AU).
Optional Accessories:
Detachable aluminum seating attachment, heavy-duty front cargo rack, and quick-swap battery mechanisms for continuous commercial fleet operations.
FAQ
Q: What is the minimum order quantity (MOQ) for custom branding?
A: The standard MOQ for custom logo laser etching, customized carton packaging, and firmware tailoring starts at 50 units per specification.
Q: What manufacturing and compliance standards are met?
A: Production facilities operate under ISO 9001 quality management standards. Export units comply with relevant electrical and mechanical safety directives (CE, FCC, RoHS, and UL2272/EN17128 where applicable).
Q: What is the standard production lead time?
A: Standard production lead times range from 25 to 35 days following deposit receipt and pre-production artwork confirmation, subject to order volume and customization complexity.
Q: How is post-purchase spare parts support managed?
A: Modular replacement components-including controllers, motors, throttles, and brake calipers-are stocked in factory inventory for direct dispatch to support long-term distributor maintenance.
Request a Quote
To obtain formal FOB/CIF pricing tiers, sample unit availability, or customized OEM specification sheets, submit your volume requirements and target destination port to our engineering sales desk.
